Main specifications
Material
S steklenimi vlakni ojačan tehnopolimer na podlagi poliamida (PA), črna barva, matirana obdelava.
Standardne verzije
- BAG2-180-A: zinc-plated steel M10 screws, nuts and washers.
- BAG2-180-SST: AISI 304 stainless steel M10 screws, nuts and washers.
Assembly on levelling elements
The bipod support bases are supplied with brass bosses, threaded pass-through hole for the assembly of the stem of the levelling element series LS.A, LV.A, LV.F.
General information
Funkcije
The rounded shapes with a modern and elegant aesthetic guarantee maximum cleanability in the event of liquids or dust falling from above.
Maximum tightening torque for screw assembly 35 Nm.
