Izvedba
Stator and rotor
Plemenito jeklo AISI 304.
Shaped closing lever
AISI 304 stainless steel, 4 mm thickness.
Matica
M22X1.5 AISI 304 stainless steel.
Tesnilni obroč
Transparent silicone rubber VMQ O-Ring, hardness 70 Shore A.
Internal gaskets
Silicone rubber VMQ O-Ring, hardness 70 Shore A.
Vijak
M6X10 AISI 304 stainless steel.
Ključ
Tehnopolimer na podlagi poliamida (PA).
Vrtenje
90°.
Zaščitni razred IP
IP66 and IP69K protection class.
Standardne izvedbe
- CQ/A-SST: two-wing groove for key.
- CQ/T-SST: triangular groove for key.
