Izvedba
Handle and stator
S steklenimi vlakni ojačan termoplast (poliamid, PA).
Rotor
Chrome-plated zinc alloy.
Front plate
Plemenito jeklo.
Matica
M22x1.5 technopolymer.
Flat closing lever
Zinc-plated steel, thickness 3 mm.
Tesnilni obroč
NBR rubber.
Self-tapping screw
Pocinkano jeklo.
Two keys
Nickel-plated brass, removable in two positions at 180°.
Vrtenje
90° clockwise (right).
Zaščitni razred IP
IP 65 protection class, according to table EN 60529.
Standardne izvedbe
- CSMT.: lock with 400 different combinations. Each lock has a couple of keys with different combination.
- CSMTU.: lock with one combination. All locks have the same combination which can be opened with the same key.
Other executions
Posebne verzije na zahtev
Closing levers in other dimensions.
