Main specifications
Osnova
S steklenimi vlakni ojačan tehnopolimer na podlagi poliamida (PA), črna barva, matirana obdelava.
Zgibno steblo
Threaded AISI 304 stainless steel with adjusting square.
Standardne verzije
- LVQ.F-SST: without no-slip disk.
- LVQ.F-AS-SST: with NBR rubber no-slip disk, hardness 70 Shore A, supplied assembled to the base.
Talna montaža
By means of two holes at 180°, supplied covered by a diaphragm (which can be easily removed by a metal tool), to avoid all unhealthy deposits of dirt and dust when the ground mounting is not required (see Fig. 1).
General information
Funkcije
Posebna narebričena površina pod spodnjim robom podlage zagotavlja odlično stabilnost in oprijem pri uporabi izravnalnega elementa brez nedrsečega diska tudi na površinah, ki niso popolnoma ravne.
The particular assembling system of the no-slip disk to the base assures a perfect anchoring, preventing separation even in case of impact during transport or of adhesion (sticking) to the floor (see Nedrseči disk).
Informacije za naročanje
The levelling elements are supplied unassembled to make carriage and storage easier. The components (base and stem) are supplied in separate packing: less volume taken and better protection from scratches and dirt.
Za ločeno naročanje osnov in stebel glejte:
tabela možnih kombinacij osnov in stebel
Dodatna oprema na zahtevo
Dodatna oprema na zahtevo
AISI 304 stainless steel nut (see Nuts NT.-).
