Main specifications
Material
S steklenimi vlakni ojačan tehnopolimer na podlagi poliamida (PA), črna barva, matirana obdelava.
Elastična vilica iz tehnopolimera na podlagi acetala (POM), črna barva.
Standardne izvedbe
- VTT-B-RC: brass boss, threaded blind hole.
- VTT-SST-RC: AISI 304 stainless steel boss, threaded blind hole.
- VTT-p-RC: zinc-plated steel threaded stud, chamfered flat end according to UNI 947 : ISO 4753 (see Tehnički podaci).
- VTT-SST-p-RC: AISI 304 stainless steel threaded stud, chamfered flat end according to UNI 947 : ISO 4753 (see Tehnički podaci).
General information
Funkcije in uporabe
Suitable where it is necessary to prevent the loss of the knob.
The elastic fork, housed in the groove of the knob can turn freely.
The three-lobe shape with large recesses is particularly ergonomic also for smaller knobs, ensuring an effective grip even with work gloves.
The design without rear cavities, generally adopted for reducing thickness, prevents unhealthy residues from depositing, ensuring easy cleaning. Particularly suitable for applications on machines and equipment whose parts must be frequently cleaned by using water jets or steam.
Dodatki
Dodatna oprema na zahtevo
- CT-S kroglične verige iz tehnopolimera in plemenitega jekla.
- GN 111 kroglične verige iz plemenitega jekla in medenine.
- CV-T zadrževalni kabli iz polietilena in plemenitega jekla.
- GN 111.2 zadrževalni kabli iz plemenitega jekla.
- GN 111.4 zadrževalni kabli iz poliuretana in spirale iz plemenitega jekla.
